| Type | T8 | T4 | |
| DIMENSIONS | Length (mm) | 3730 (12'3") | |
| Width (mm) | 2820 (9'3") | ||
| Height (mm) | 2495 (8'2") | ||
| Full Extending Height (mm) | 9 (29'7") | ||
| Gross Weight (kg) | 1850/4034 | 1800/4000 | |
| ENGINE | Engine | KD440 (KOHLER) | |
| Rotational Speed (rpm) | 3000/3600 | ||
| Number of Cylinder | 1 | ||
| Engine Character | 4 cycles, air-cooled diesel | ||
| Combustion System | Direct Injection | ||
| Engine Aspiration | Naturally aspirated | ||
| Emission Level | Regular | ||
| ALTERNATOR | Standard Configuration | SP10MG (LINZ) | |
| Frequency (Hz) | 50/60 | ||
| Rating Voltage (V, AC) | 230 (AC) | ||
| Alternator Insulation | Class H | ||
| Alternator Protection Grade | IP 23 | ||
| MASS & LIGHTS | Type of Lights | LED | Regular metal halide |
| Light's Fixtures | Rectangle | Rectangle (GEWISS) | |
| Luminous Flux (LM/Light) | 39000 | 110000 | |
| Number & Power (W) | 8 x 300 | 4 x 1000 | |
| Number of Mass Section | 3 | ||
| Mass Lifting | Hydraulic | ||
| Mass Extension | Hydraulic | ||
| Mass Rotation | Hydraulic | ||
| Light Bar Tilt | 12VDC Electric Linear Actuator | ||
| TRAILER | Axle with Suspension & Axle Brake | SWT Standard leaf springs & single axle with mechanical drum brakes | |
| Tow Bar | Retractable & adjustable supporting wheel tow bar | ||
| Stabilizing Legs & Number | 4pcs Hydraulic retractable legs | ||
| Wheel's Rim Size & Tires | 16" rim with off road tires | ||
| Tow Adapter | Tall light kit | ||
| Max Towing Speed (km/H) | 100 (62mph) | ||
| ADDITIONAL FEATURES | Electric Standard & Configuration | SWT Australia Electric Standard, Australia & Mining Configuration | |
| Fuel Tank Type | Double Wall | ||
| Fuel Tank Capacity | 80 | ||
| Operating Hours | 88 | 53 | |
| Hydraulic Components | Mining Standard Hose | ||
| Wires & Electric Component | IP 65 | ||
| Generator Starting Type or Controller | SUNIGHT-002 | ||
| Running Indicator of Generator | Rotating LED Light | ||
| Extinguisher | Only Supply the Mounting Bracket | ||
| Max Against Wind (m/s) | 22 (50mph) | ||
| Acoustic Pressure | |||
