| Type | TL-4000 | |
| DIMENSIONS | Length (mm) | 3420 (11'2") |
| Width (mm) | 2800 (9'2") | |
| Height (mm) | 2460 (8'1") | |
| Full Extending Height (mm) | 8,84 (29') | |
| Gross Weight (kg/lbs) | 1410 (3110 lb) | |
| ENGINE | Engine | D1105 (KUBOTA) |
| Rotational Speed (rpm) | 1500/1800 | |
| Number of Cylinder | 3 | |
| Engine Character | 4cycles, watercooled diesel | |
| Combustion System | E-TVS | |
| Engine Aspiration | Naturally Aspirated | |
| Emission Level | Regular | |
| ALTERNATOR | Standard Configuration | SPARKS |
| Frequency (Hz) | 50/60 | |
| Rating Voltage | 230/240-120VAC | |
| Alternator Insulation | Class H | |
| Alternator Protection Grade | IP 23 | |
| MAST & LIGHTS | Type of Light | Regular metal halide |
| Light's Fixture | Rectangle (GEWISS) | |
| Luminous Flux | 110000 LM/Light | |
| Number & Power of Lights (W) | 4 x 1000 | |
| Number of Mast Section | 7 | |
| Mast Extension | Hydraulic | |
| Mass Rotation | Manually, Max. 330 Lockable | |
| Light Bar Tilt | 12VDC Electric Linear Actuator | |
| TRAILER | Trailer Suspension & Axle with Brakes | Leaf springs & Single axle with mechanical brakes |
| Tow Bar | Retractable & Adjustable supporting | |
| Stabilizing Legs & Number | 4 pcs extendable bar with manually retractable jacks | |
| Wheel's Rim Size & Tires | 16" Rim with regular tires | |
| Tow Adapter | 2" or 50mm ball adapter | |
| Tail Lights | Tail Light Kit | |
| Max Towing Speed (km/H) | 100 (62mph) | |
| ADDITIONAL FEATURES | Fuel Tank Type | Double wall sub-fueltank |
| Operating Hours (hours) | 84 | |
| Wires & Electric Components | Regular | |
| Generator Controller | DSE 702AS | |
| Max Againts Wind (m/s) | 20 (45mph) | |
| Accoustic Pressure |
